EC Compact Axial Flow Fans - Slim EC Axial Fans

Home > EC Compact Axial Flow

EC Compact Axial Flow

1 results

By type

By industry

Rated Voltage(V)

Size(mm)

Max.Air Flow(m³/h)

Max.Pressure(Pa)

Input Power(W)

Speed(rpm)

Noise(db)

Applied Filters

Showing

1-1

of 1

Featured Most Popular

Download Table

	Mfr Part #	Rated Voltage(V)	Size(mm)	Max.Air Flow(m³/h)	Max.Pressure(Pa)	Input Power(W)	Speed(rpm)	Noise(db)

	AC4300H \| ebm-papst 115V 12W EC Axial Fan for Electronics Cooling The ebm-papst AC4300H is a high-performance ec axial fan engineered for electronics and industrial equipment. It provides reliable airflow and efficient thermal management for demanding equipment.	115	11911932	204	-	12	3400	51

Showing

1-1

of 1

About EC Compact Axial Flow

Compact EC axial flow fans bring the energy efficiency advantages of EC technology to small-form-factor applications — typically ranging from 40mm to 120mm in frame size. Like their larger counterparts, compact EC fans use Electronically Commutated motors that achieve dramatically higher efficiency than both AC and brushed DC alternatives while delivering variable speed capability via PWM or 0-10V control. The compact EC axial fan category has grown rapidly in recent years as equipment manufacturers seek to reduce energy consumption and meet increasingly stringent global energy efficiency regulations (including ErP in the EU and DOE standards in the US). Compact EC fans are used in premium electronics (high-end gaming PCs, workstations), modern home appliances (inverter air conditioners, variable-speed refrigerators), and next-generation telecommunication equipment. Leading manufacturers include ebm-papst (compact GreenTech EC range) and Rosenberg. Key selection parameters include frame size, operating voltage, efficiency rating, noise level, and PWM control compatibility. Hengrui offers competitive pricing and inventory availability for compact EC axial fans from all major global manufacturers.

How to Select the Right EC Compact Axial Flow

The most reliable way to specify EC Compact Axial Flow is to work from the system, not from the catalog. Measure or calculate the airflow and pressure demand first, add the dimensional limits of the mounting position, and only then shortlist series whose curves cover your operating point with margin.

Electrical matching is the next gate. Confirm the supply voltage — 12 V, 24 V or 48 V DC for compact electronics cooling, 115 V or 230 V AC for equipment and panel cooling — and decide whether you need speed control. EC models accept PWM or 0-10 V signals and report speed through a tachometer output, which makes them the default choice for variable-airflow systems, while AC units remain a cost-effective answer for fixed-speed duty.

Then filter by environment. High ambient temperature, dust or moisture loads dictate the IP rating and bearing choice — ball bearings keep airflow and noise stable over years, while sleeve bearings suit light-duty horizontal mounting. Regulatory needs such as UL, CE and RoHS recognition should be confirmed before the shortlist goes to purchasing, together with a maximum allowed sound pressure level in dBA.

End the process by checking supply, not just specification: confirm current stock, the lead time for follow-up quantities, and obtain datasheets and dimension drawings so the mechanical interface is verified before the PO. Send us your airflow and pressure requirements and our engineers will confirm the best-matched series — 1 products are available in this category today.

Typical Applications and Use Cases for EC Compact Axial Flow

The daily work of our sales engineers is built around EC Compact Axial Flow used in data center cooling, refrigeration and cold chain projects, building ventilation, telecom base stations, medical devices and industrial control cabinets — environments where a stopped fan is a stopped business process. That daily exposure to real installations is exactly what we bring back into every selection: not just reading curves, but knowing which models survive dust, heat, continuous duty and restricted service access.

A typical case: an equipment builder needed to replace an aging AC fan inside a control cabinet that could not be taken offline for more than an hour. By cross-referencing the frame dimensions, voltage and airflow curve, we supplied a current-series drop-in replacement with a matching tachometer signal, and the swap was completed during a scheduled maintenance window.

Refrigeration and cold chain customers bring us another pattern: the failed condenser fan is unavailable for weeks. Comparing diameter, speed, bearings and IP rating, we supply a functionally equivalent unit from stock so the system returns to duty the same week — the reason many service companies keep our contact number on file.

From one-piece emergency replacements to volume supply for equipment manufacturers, every ebmpapst enquiry is handled by the same rule: verify the parameters first, then quote — so what arrives on site is the fan the project actually needs.

Frequently Asked Questions About Buying EC Compact Axial Flow

What technical documentation do you provide before purchase?

Datasheets, performance curves, dimension drawings and certification files (UL, CE, RoHS where applicable) are available on request before you buy — we believe a purchase order should follow a verified selection, not replace it. For project tenders we can also provide product comparison tables that put the candidate models side by side on the parameters you care about.

Do you have EC Compact Axial Flow in stock and how fast can you deliver?

Common series and mainstream voltage versions are normally in stock and can ship within a few working days; specialized or customized variants are produced to order and typically require additional production time. Send us the exact model or the required parameters and we will confirm stock, unit price and the earliest shipment date in one reply Currently 1 products in this category are listed online.

Can you replace my existing EC Compact Axial Flow from another supplier or a discontinued model?

Yes. Replacement supply is one of our core services: we cross-reference the mounting dimensions, voltage, speed and performance curve of your installed unit and propose the closest current-series equivalent. Where the frame or connector differs slightly, we state the difference clearly before you order, so the replacement installs without surprises.

Bag

Bag packaging indicates that a specified quantity of product is packaged by the manufacturer in a bag, sealed pouch, or similar container and sold as a unit without repackaging. It is also used to describe kits/assortments where components are packaged in separate bags according to part number or parametric value, rather than in a compartmentalized box or similar rigid container.
