109E5724K5H01 Sanyo Axial Fan

Brand :: Sanyo

Model:: 109E5724K5H01 | Sanyo Denki 24VDC DC Axial Fan for UPS, server and telecom equipment cooling

Type:: Axial Fans

Industry:: Data Center Cooling

Description:: The 172 × 150 × 51 mm Sanyo Denki 109E5724K5H01 brings 24 VDC DC axial fan cooling to servers, UPS systems, and telecom equipment. High airflow is highlighted together with a high-static-pressure design. During thermal validation, compare the model's operating point. Treat bearing and life data as suffix-specific.

Datasheet:: 109E5724K5H01 | Sanyo Denki 24VDC DC Axial Fan for UPS, server and telecom equipment cooling Datasheet (Pdf)

Product Features

Rated Voltage(V)	24
Size(mm)	17215051

Product Features

Reliable Fan Cooling

SANYO DENKI positions 109E5724K5H01 as a DC axial fan for servers, storage systems and ICT equipment. It helps equipment designers manage local hot spots where natural convection is insufficient.

Engineers should review the model-specific fan curve against filters, grilles and enclosure resistance to confirm the required operating point. For design approval, verify airflow direction, connector details and available control signals. Prototype testing should include the final vents, guards and component loading.

Keep the impeller path clear of wiring. It also creates a clearer thermal approval record. Confirm the final fan curve in the assembled equipment. Preserve clear inlet and outlet space during installation.

Application Industry

Server Cooling

109E5724K5H01 is suitable for server chassis and computing nodes. These systems need continuous heat removal because compact layouts and rising power density restrict natural convection. It provides a practical cooling path for OEM integration. Selection should follow the approved full model code.

Storage Systems

The San Ace 109E5724K5H01 supports thermal management in storage arrays and data appliances. These systems need continuous heat removal because compact layouts and rising power density restrict natural convection. It provides a practical cooling path for OEM integration.

ICT Equipment

For network and other ICT hardware, 109E5724K5H01 provides a dedicated forced-air cooling path. These systems need continuous heat removal because compact layouts and rising power density restrict natural convection. It provides a practical cooling path for OEM integration.

Frequently Asked Questions

Is 109E5724K5H01 easy to install and maintain?

Confirm connector and mounting details, keep the airflow path clear, and isolate power before cleaning or service.

How should 109E5724K5H01 be matched to an enclosure?

Check its 172 × 150 × 51 mm size, mounting points, airflow direction, and system resistance.

What certifications apply to 109E5724K5H01?

The workbook marks it RoHS compliant. Confirm model-specific UL, CSA, TÜV, or other required approvals from official documentation.

Which application details matter most for 109E5724K5H01?

Review ambient temperature, airflow restriction, contamination exposure, noise limit, mounting orientation, and maintenance access.

What maintenance does 109E5724K5H01 require?

Inspect dust buildup, airflow blockage, abnormal noise, mounting security, and wiring condition; disconnect power before service.
