109L1724H501 Sanyo Axial Fan

Brand :: Sanyo

Model:: 109L1724H501 | Sanyo Denki 24VDC 13.92W DC Axial Fan for UPS, server and telecom equipment cooling

Type:: Axial Fans

Industry:: Data Center Cooling

Description:: A ø172 × 51 mm frame and 24 VDC rating define 109L1724H501, a DC axial fan for servers, UPS systems, and telecom equipment. High airflow is highlighted together with a high-static-pressure design. Its listed airflow of 384.2 m³/h is the standout performance value. Check equipment integration review sound level. Focus: equipment integration review.

Datasheet:: 109L1724H501 | Sanyo Denki 24VDC 13.92W DC Axial Fan for UPS, server and telecom equipment cooling Datasheet (Pdf)

Product Features

Rated Voltage(V)	24
Size(mm)	ø172*51
Max.Air Flow(m³/h)	384.2
Max.Pressure(Pa)	137.2
Input Power(W)	13.92
Speed(rpm)	3050

Product Features

Low Vibration Fan

SANYO DENKI positions 109L1724H501 as a DC axial fan for servers, storage systems and ICT equipment. It helps equipment designers manage local hot spots where natural convection is insufficient.

The rated peak airflow of 384.2 m3/h combines with 137.2 Pa pressure capability to support useful flow after installation losses are considered. Buyers should confirm the complete suffix, connector, sensor output and control option before ordering. Engineers should validate the operating point with the actual grille and filter.

Review airflow direction before design release. It also creates a clearer thermal approval record. Confirm the final fan curve in the assembled equipment. Preserve clear inlet and outlet space during installation.

Application Industry

Server Cooling

For server chassis and computing nodes, 109L1724H501 provides a dedicated forced-air cooling path. Reliable ventilation reduces hot spots around sensitive electronics and supports consistent equipment availability. The application supports stable equipment service.

Storage Systems

SANYO DENKI 109L1724H501 serves storage arrays and data appliances that operate with sustained internal heat. Reliable ventilation reduces hot spots around sensitive electronics and supports consistent equipment availability. The application supports stable equipment service.

ICT Equipment

109L1724H501 is suitable for network and other ICT hardware. Air circulation around processors, power devices and control electronics limits heat concentration and supports stable operation. It supports reliable OEM equipment cooling. Selection should follow the approved full model code.

Frequently Asked Questions

What airflow is listed for 109L1724H501?

The worksheet lists 384.2 m³/h. Compare the operating point with system resistance and the official performance curve.

Why choose 109L1724H501 instead of a standard fan?

Its 24 VDC rating and documented its listed airflow of 384.2 m³/h is the standout performance value. provide model-specific selection data without relying on unlisted claims.

What supply voltage does 109L1724H501 require?

The worksheet lists 24 VDC. Check polarity or AC frequency and the wiring diagram before commissioning.

Can 109L1724H501 run continuously in a 24/7 system?

Verify the exact bearing, rated life, temperature range, and duty limits. The supplied family description alone does not confirm continuous operation for every suffix.

What bearing type does 109L1724H501 use?

The exact bearing is not stated in the supplied row. Confirm it from the complete model suffix and current Sanyo Denki datasheet.
