109R0805F401 Sanyo Axial Fan

Brand :: Sanyo

Model:: 109R0805F401 | Sanyo Denki 5VDC 1.25W DC Axial Fan for UPS, server and telecom equipment cooling

Type:: Axial Fans

Industry:: Data Center Cooling

Description:: The 109R0805F401 is a Sanyo Denki 5 VDC, 80 × 80 × 25 mm DC axial fan for servers, UPS systems, and telecom equipment. High airflow is highlighted together with a high-static-pressure design. Base equipment integration on the stated supply requirement. Obtain the applicable curve before final duty-point approval. Focus: cooling margin validation.

Product Features

Rated Voltage(V)	5
Size(mm)	808025
Max.Air Flow(m³/h)	54.6
Max.Pressure(Pa)	28.4
Input Power(W)	1.25
Speed(rpm)	2600
Noise(db)	26

Product Features

Reliable Fan Cooling

109R0805F401 brings San Ace DC axial fan cooling to servers, storage systems and ICT equipment. The compact air-moving design suits OEM assemblies that require continuous ventilation around electronic and power components.

The rated peak airflow of 54.6 m3/h combines with 28.4 Pa pressure capability to support useful flow after installation losses are considered. Selection should include a system-resistance review, mounting check and harness confirmation. The full model code matters because signal and lead options can differ within a series.

Assess vibration transfer into enclosure panels. This step reduces uncertainty during equipment qualification. Confirm the final fan curve in the assembled equipment.

Application Industry

Server Cooling

For server chassis and computing nodes, 109R0805F401 provides a dedicated forced-air cooling path. These systems need continuous heat removal because compact layouts and rising power density restrict natural convection. The application supports stable equipment service.

Storage Systems

SANYO DENKI 109R0805F401 serves storage arrays and data appliances that operate with sustained internal heat. These systems need continuous heat removal because compact layouts and rising power density restrict natural convection. The application supports stable equipment service.

ICT Equipment

109R0805F401 is suitable for network and other ICT hardware. Directed airflow carries component heat toward the equipment exhaust and helps maintain a controlled internal temperature. The application supports stable equipment service. Selection should follow the approved full model code.

Frequently Asked Questions

Is 109R0805F401 suitable for high-reliability cooling?

Evaluate the exact bearing, life, temperature, alarm, and protection data. Correct sizing and clean airflow are also required for reliable operation.

Which application details matter most for 109R0805F401?

Review ambient temperature, airflow restriction, contamination exposure, noise limit, mounting orientation, and maintenance access.

What maintenance does 109R0805F401 require?

Inspect dust buildup, airflow blockage, abnormal noise, mounting security, and wiring condition; disconnect power before service.

What is the lead time for 109R0805F401?

Availability and lead time can change. Confirm the exact suffix, quantity, and delivery date with the supplier before ordering.

How noisy is 109R0805F401?

The worksheet lists 26 dB. Enclosure acoustics, system resistance, and distance can change the installed result.
