109S-303 Sanyo Axial Fan

Brand :: Sanyo

Model:: 109S-303 | Sanyo Denki 230VAC 25W AC Axial Fan for automation and control cabinet cooling

Type:: Axial Fans

Industry:: Automation

Description:: Built around servers, UPS systems, and telecom equipment, Sanyo Denki 109S-303 is a 230 VAC AC axial fan in a 172 × 150 × 51 mm frame. Its listed airflow of 379.8 m³/h is the standout performance value. Series options require suffix verification. Focus: acoustic limit assessment suffix definition.

Datasheet:: 109S-303 | Sanyo Denki 230VAC 25W AC Axial Fan for automation and control cabinet cooling Datasheet (Pdf)

Product Features

Rated Voltage(V)	230
Size(mm)	17215051
Max.Air Flow(m³/h)	379.8
Max.Pressure(Pa)	196
Input Power(W)	25
Speed(rpm)	3500
Noise(db)	56

Product Features

Efficient Cooling

SANYO DENKI positions 109S-303 as a AC axial fan for automation controls, PLC cabinets and drive systems. It helps equipment designers manage local hot spots where natural convection is insufficient.

Its 379.8 m3/h maximum airflow supports rapid air exchange, while 196 Pa pressure capability helps overcome resistance within the finished equipment. Selection should include a system-resistance review, mounting check and harness confirmation. The full model code matters because signal and lead options can differ within a series.

Preserve outlet space to limit recirculation. It supports stable operation across the intended load cycle. Confirm the final fan curve in the assembled equipment. Preserve clear inlet and outlet space during installation.

Application Industry

Control Cabinets

SANYO DENKI 109S-303 serves automation and electrical control cabinets that operate with sustained internal heat. These systems need continuous heat removal because compact layouts and rising power density restrict natural convection. It supports reliable OEM equipment cooling.

PLC Systems

109S-303 is suitable for PLC and motion-control equipment. Directed airflow carries component heat toward the equipment exhaust and helps maintain a controlled internal temperature. It supports reliable OEM equipment cooling. Selection should follow the approved full model code.

Variable Speed Drives

The San Ace 109S-303 supports thermal management in inverters and industrial drive systems. Directed airflow carries component heat toward the equipment exhaust and helps maintain a controlled internal temperature. It supports reliable OEM equipment cooling.

Frequently Asked Questions

How noisy is 109S-303?

The worksheet lists 56 dB. Enclosure acoustics, system resistance, and distance can change the installed result.

What speed is listed for 109S-303?

The listed speed is 3500 rpm. Confirm control conditions and the actual duty point.

Is 109S-303 easy to install and maintain?

Confirm connector and mounting details, keep the airflow path clear, and isolate power before cleaning or service.

Which specifications define 109S-303?

Use rated voltage, 172 × 150 × 51 mm dimensions, 379.8 m³/h airflow, 3500 rpm, and 25 W input for preliminary comparison.

What equipment is 109S-303 suited to?

It is listed for servers, UPS systems, and telecom equipment. Confirm airflow, pressure, dimensions, and environmental conditions against the actual equipment.

What IP protection is documented for 109S-303?

No exact IP rating is supplied for this model row. Check the current model datasheet before use in water, dust, or oil exposure.
