9A0924S4D01 Sanyo Axial Fan

Brand :: Sanyo

Model:: 9A0924S4D01 | Sanyo Denki 24VDC 3.6W DC Axial Fan for UPS, server and telecom equipment cooling

Type:: Axial Fans

Industry:: Data Center Cooling

Description:: For servers, UPS systems, and telecom equipment, 9A0924S4D01 combines 24 VDC operation with a 92 × 92 × 25 mm DC axial fan design. Series focus: high airflow and pressure. 56 Pa maximum pressure is the most distinctive duty-point parameter. Check airflow path balancing mounting size. Focus: airflow path balancing mounting size.

Product Features

Rated Voltage(V)	24
Size(mm)	929225
Max.Air Flow(m³/h)	98.4
Max.Pressure(Pa)	56
Input Power(W)	3.6
Speed(rpm)	3550
Noise(db)	39

Product Features

Reliable Fan Cooling

The San Ace 9A0924S4D01 serves servers, storage systems and ICT equipment as a DC axial fan. Its airflow supports heat transfer from internal devices toward cabinet or chassis exhaust openings.

A listed maximum airflow of 98.4 m3/h and maximum pressure of 56 Pa give engineers a clear basis for matching the fan to enclosure resistance. The fan converts electrical input into focused air movement for efficient cooling. Its mechanical layout supports repeatable installation and dependable operation in OEM equipment. For design approval, verify airflow direction, connector details and available control signals. Prototype testing should include the final vents, guards and component loading.

Keep the impeller path clear of wiring. The process documents the required installation conditions.

Application Industry

Server Cooling

9A0924S4D01 is suitable for server chassis and computing nodes. Air circulation around processors, power devices and control electronics limits heat concentration and supports stable operation. It provides a practical cooling path for OEM integration.

Storage Systems

The San Ace 9A0924S4D01 supports thermal management in storage arrays and data appliances. Air circulation around processors, power devices and control electronics limits heat concentration and supports stable operation. It provides a practical cooling path for OEM integration.

ICT Equipment

For network and other ICT hardware, 9A0924S4D01 provides a dedicated forced-air cooling path. Air circulation around processors, power devices and control electronics limits heat concentration and supports stable operation. It provides a practical cooling path for OEM integration.

Frequently Asked Questions

What IP protection is documented for 9A0924S4D01?

No exact IP rating is supplied for this model row. Check the current model datasheet before use in water, dust, or oil exposure.

Does 9A0924S4D01 support PWM speed control?

PWM or sensor functions depend on the exact suffix. Confirm the control lead and interface in the applicable Sanyo Denki datasheet.

What is the lead time for 9A0924S4D01?

Availability and lead time can change. Confirm the exact suffix, quantity, and delivery date with the supplier before ordering.

What supply voltage does 9A0924S4D01 require?

The worksheet lists 24 VDC. Check polarity or AC frequency and the wiring diagram before commissioning.

What should be checked if 9A0924S4D01 stops?

Verify supply, connector, obstructions, impeller movement, and alarm or protection status using the model-specific troubleshooting data.
