9GA1224P4G0011 Sanyo Axial Fan

Brand :: Sanyo

Model:: 9GA1224P4G0011 | Sanyo Denki 24VDC 11.28W DC Axial Fan for UPS, server and telecom equipment cooling

Type:: Axial Fans

Industry:: Data Center Cooling

Description:: Sanyo Denki configures 9GA1224P4G0011 for servers, UPS systems, and telecom equipment as a 24 VDC DC axial fan with 120×120×25 mm dimensions. 365 Pa maximum pressure is the most distinctive duty-point parameter. Use the documented suffix definition when planning replacement evaluation. Match the exact part number before approving a substitute.

Datasheet:: 9GA1224P4G0011 | Sanyo Denki 24VDC 11.28W DC Axial Fan for UPS, server and telecom equipment cooling Datasheet (Pdf)

Product Features

Rated Voltage(V)	24
Size(mm)	120×120×25
Max.Air Flow(m³/h)	228
Max.Pressure(Pa)	365
Input Power(W)	11.28
Speed(rpm)	6400
Noise(db)	57

Product Features

Reliable Fan Cooling

The San Ace 9GA1224P4G0011 serves servers, storage systems and ICT equipment as a DC axial fan. Its airflow supports heat transfer from internal devices toward cabinet or chassis exhaust openings.

The rated peak airflow of 228 m3/h combines with 365 Pa pressure capability to support useful flow after installation losses are considered. For design approval, verify airflow direction, connector details and available control signals. Prototype testing should include the final vents, guards and component loading.

Qualify performance with the production guard. It supports a clear fan specification for future servicing. Confirm the final fan curve in the assembled equipment. Preserve clear inlet and outlet space during installation.

Application Industry

Server Cooling

For server chassis and computing nodes, 9GA1224P4G0011 provides a dedicated forced-air cooling path. These systems need continuous heat removal because compact layouts and rising power density restrict natural convection. The application supports stable equipment service.

Storage Systems

SANYO DENKI 9GA1224P4G0011 serves storage arrays and data appliances that operate with sustained internal heat. These systems need continuous heat removal because compact layouts and rising power density restrict natural convection. The application supports stable equipment service.

ICT Equipment

9GA1224P4G0011 is suitable for network and other ICT hardware. Directed airflow carries component heat toward the equipment exhaust and helps maintain a controlled internal temperature. The application supports stable equipment service. Selection should follow the approved full model code.

Frequently Asked Questions

Which application details matter most for 9GA1224P4G0011?

Review ambient temperature, airflow restriction, contamination exposure, noise limit, mounting orientation, and maintenance access.

What maintenance does 9GA1224P4G0011 require?

Inspect dust buildup, airflow blockage, abnormal noise, mounting security, and wiring condition; disconnect power before service.

Why choose 9GA1224P4G0011 instead of a standard fan?

Its 24 VDC rating and documented 365 pa maximum pressure is the most distinctive duty-point parameter. provide model-specific selection data without relying on unlisted claims.

How noisy is 9GA1224P4G0011?

The worksheet lists 57 dB. Enclosure acoustics, system resistance, and distance can change the installed result.

What should be checked if 9GA1224P4G0011 stops?

Verify supply, connector, obstructions, impeller movement, and alarm or protection status using the model-specific troubleshooting data.
