PMD4806PTVX-A.U.GN SUNON Axial Fan

Brand :: SUNON

Model:: PMD4806PTVX-A.U.GN | SUNON 48V 5.5W 60x60x25mm 68m3/h DC Axial Fan for Industrial Cooling

Type:: Axial Fans

Industry:: Industrial Cooling

Description:: For ventilation needs in industrial electronics and equipment cooling, the PMD4806PTVX-A.U.GN provides a 48 VDC DC blower configuration measuring 60 × 60 × 25 mm. 7600 rpm is the model's most distinctive operating parameter. Review its frame geometry during acoustic assessment. Match the exact part number before approving a substitute.

Datasheet:: PMD4806PTVX-A.U.GN | SUNON 48V 5.5W 60x60x25mm 68m3/h DC Axial Fan for Industrial Cooling Datasheet (Pdf)

Product Features

Rated Voltage(V)	48
Size(mm)	606025
Max.Air Flow(m³/h)	68
Input Power(W)	5.5
Speed(rpm)	7600
Noise(db)	45

Product Features

MagLev Cooling

SUNON PMD4806PTVX-A.U.GN brings active air movement to industrial equipment. This DC brushless axial fan helps equipment designers control thermal conditions around densely arranged parts.

SUNON's DC product line is developed around MagLev motor technology, supporting low-friction rotation, energy-conscious operation and long service life in compact formats.

The final PMD4806PTVX-A.U.GN selection should consider connector reach as part of the installation layout. Finishing thermal-load testing during prototype approval helps reduce integration uncertainty and supports reliable equipment cooling. Confirm that the mating lead reaches without tension or sharp bending. The final assembly should be tested under its expected thermal load.

Application Industry

Industrial Equipment

SUNON PMD4806PTVX-A.U.GN serves industrial machinery and electronic equipment. Airflow around controllers, drives and power devices helps address continuous internal heat. The fan gives OEM equipment a defined air route and supports stable equipment operation.

Frequently Asked Questions

Which selection data still require confirmation for PMD4806PTVX-A.U.GN?

Confirm any missing bearing, connector, control, IP rating, life, certification, and performance-curve details for the complete part number.

What maintenance is recommended for PMD4806PTVX-A.U.GN?

Inspect for dust, blocked airflow, abnormal noise, loose mounting, and wiring damage. Isolate power before cleaning or service.

How should buyers confirm availability of PMD4806PTVX-A.U.GN?

Stock and lead time can change. Confirm the exact suffix, quantity, and delivery date with the supplier before ordering.

What speed is listed for PMD4806PTVX-A.U.GN?

The listed speed is 7600 rpm. Confirm frequency, control method, and duty point for the installed system.

Is PMD4806PTVX-A.U.GN suitable for continuous operation?

The supplied product-line reference discusses long-life cooling, but continuous-duty limits for this full suffix must be verified from its datasheet and operating conditions.
