9G1224H101 Sanyo Axial Fan

Brand :: Sanyo

Model:: 9G1224H101 | Sanyo Denki 24VDC 5.28W DC Axial Fan for UPS, server and telecom equipment cooling

Type:: Axial Fans

Industry:: Data Center Cooling

Description:: For thermal management in servers, UPS systems, and telecom equipment, the 9G1224H101 provides a 24 VDC DC axial fan configuration measuring 120 × 120 × 38 mm. Its 2600 rpm rating defines a lower-speed operating point. Treat the motor input as a primary input to mounting verification. Validate mounting and wiring from the model drawing.

Product Features

Rated Voltage(V)	24
Size(mm)	12012038
Max.Air Flow(m³/h)	168
Max.Pressure(Pa)	70.4
Input Power(W)	5.28
Speed(rpm)	2600
Noise(db)	39

Product Features

Pressure Cooling

The San Ace 9G1224H101 serves servers, storage systems and ICT equipment as a DC axial fan. Its airflow supports heat transfer from internal devices toward cabinet or chassis exhaust openings.

The rated peak airflow of 168 m3/h combines with 70.4 Pa pressure capability to support useful flow after installation losses are considered. The motor, frame and impeller form a rigid airflow assembly that helps control vibration and preserve operating stability. Efficient air delivery reduces unnecessary cooling overhead. Buyers should confirm the complete suffix, connector, sensor output and control option before ordering. Engineers should validate the operating point with the actual grille and filter.

Include filter loading in the airflow margin. The result supports repeatable OEM assembly.

Application Industry

Server Cooling

For server chassis and computing nodes, 9G1224H101 provides a dedicated forced-air cooling path. Air circulation around processors, power devices and control electronics limits heat concentration and supports stable operation. The application supports stable equipment service.

Storage Systems

SANYO DENKI 9G1224H101 serves storage arrays and data appliances that operate with sustained internal heat. Air circulation around processors, power devices and control electronics limits heat concentration and supports stable operation. The application supports stable equipment service.

ICT Equipment

9G1224H101 is suitable for network and other ICT hardware. These systems need continuous heat removal because compact layouts and rising power density restrict natural convection. The application supports stable equipment service. Selection should follow the approved full model code.

Frequently Asked Questions

Which application details matter most for 9G1224H101?

Review ambient temperature, airflow restriction, contamination exposure, noise limit, mounting orientation, and maintenance access.

Does 9G1224H101 support PWM speed control?

PWM or sensor functions depend on the exact suffix. Confirm the control lead and interface in the applicable Sanyo Denki datasheet.

Why choose 9G1224H101 instead of a standard fan?

Its 24 VDC rating and documented its 2600 rpm rating defines a lower-speed operating point. provide model-specific selection data without relying on unlisted claims.

What input power is listed for 9G1224H101?

The worksheet lists 5.28 W. Check supply capacity and operating conditions before commissioning.

What speed is listed for 9G1224H101?

The listed speed is 2600 rpm. Confirm control conditions and the actual duty point.
