PMD2408PMB1-A-L88 SUNON Axial Fan

Brand :: SUNON

Model:: PMD2408PMB1-A-L88 | SUNON 24V 9.6W 80x80x38mm 142.9m3/h DC Axial Fan for Industrial Cooling

Type:: Axial Fans

Industry:: Industrial Cooling

Description:: SUNON configures PMD2408PMB1-A-L88 as a 80 × 80 × 38 mm DC blower for industrial electronics and equipment cooling, operating at 24 VDC. 184.3 Pa maximum pressure is the standout documented duty-point value. For engineering comparison, start with the supplied performance curve. Confirm temperature and service-life limits from current data.

Datasheet:: PMD2408PMB1-A-L88 | SUNON 24V 9.6W 80x80x38mm 142.9m3/h DC Axial Fan for Industrial Cooling Datasheet (Pdf)

Product Features

Rated Voltage(V)	24
Size(mm)	80x80x38mm
Max.Air Flow(m³/h)	142.9
Max.Pressure(Pa)	184.3
Input Power(W)	9.6
Speed(rpm)	5700
Noise(db)	55.2

Product Features

Reliable Fan Cooling

SUNON PMD2408PMB1-A-L88 brings active air movement to industrial equipment. This DC brushless axial fan helps equipment designers control thermal conditions around densely arranged parts.

The brushless DC motor architecture supports efficient electronic commutation and stable rotational performance for compact equipment cooling. Rigid mounting and clear breathing space help control vibration, flow loss and the acoustic result of the complete assembly.

A dependable PMD2408PMB1-A-L88 installation starts with a review of exhaust separation. Complete wiring verification before volume production to confirm compatibility, operating margin and the information needed for repeat orders. Separate discharge air from the intake path inside the finished enclosure.

Application Industry

Industrial Equipment

SUNON PMD2408PMB1-A-L88 serves industrial machinery and electronic equipment. Airflow around controllers, drives and power devices helps address continuous internal heat. The fan gives OEM equipment a defined air route and supports stable equipment operation.

Frequently Asked Questions

Can PMD2408PMB1-A-L88 serve high-reliability cooling systems?

Assess reliability from the exact bearing, temperature, protection, and life data. The supplied series note alone does not confirm every suffix-specific option.

Which selection data still require confirmation for PMD2408PMB1-A-L88?

Confirm any missing bearing, connector, control, IP rating, life, certification, and performance-curve details for the complete part number.

What maintenance is recommended for PMD2408PMB1-A-L88?

Inspect for dust, blocked airflow, abnormal noise, loose mounting, and wiring damage. Isolate power before cleaning or service.

How can PMD2408PMB1-A-L88 affect operating cost?

Compare its listed 9.6 W input with the required airflow and run time. Total savings depend on the complete system duty point.

What noise data are available for PMD2408PMB1-A-L88?

The worksheet lists 55.2 dB. Installation distance, airflow resistance, and enclosure acoustics can change the measured result.
