109P0424R3023 Sanyo Axial Fan

Brand :: Sanyo

Model:: 109P0424R3023 | Sanyo Denki 24VDC 6W DC Axial Fan for UPS, server and telecom equipment cooling

Type:: Axial Fans

Industry:: Data Center Cooling

Description:: The 109P0424R3023 is a Sanyo Denki 24 VDC, 40 × 40 × 28 mm DC axial fan for servers, UPS systems, and telecom equipment. High airflow is highlighted together with a high-static-pressure design. Review its installation footprint during procurement comparison. Confirm environmental protection for the ordered version. Focus: thermal margin assessment.

Product Features

Rated Voltage(V)	24
Size(mm)	404028
Max.Air Flow(m³/h)	30.2
Max.Pressure(Pa)	263.3
Input Power(W)	6
Speed(rpm)	14000
Noise(db)	47

Product Features

Reliable Fan Cooling

109P0424R3023 is intended for dependable forced-air cooling in servers, storage systems and ICT equipment. This SANYO DENKI DC axial fan fits equipment designs where thermal stability affects service continuity.

A listed maximum airflow of 30.2 m3/h and maximum pressure of 263.3 Pa give engineers a clear basis for matching the fan to enclosure resistance. For design approval, verify airflow direction, connector details and available control signals. Prototype testing should include the final vents, guards and component loading.

Map airflow around the hottest components. It helps maintenance teams plan compatible replacements. Confirm the final fan curve in the assembled equipment. Preserve clear inlet and outlet space during installation.

Application Industry

Server Cooling

109P0424R3023 is suitable for server chassis and computing nodes. Directed airflow carries component heat toward the equipment exhaust and helps maintain a controlled internal temperature. This helps maintain dependable equipment operation. Selection should follow the approved full model code.

Storage Systems

The San Ace 109P0424R3023 supports thermal management in storage arrays and data appliances. Directed airflow carries component heat toward the equipment exhaust and helps maintain a controlled internal temperature. This helps maintain dependable equipment operation.

ICT Equipment

For network and other ICT hardware, 109P0424R3023 provides a dedicated forced-air cooling path. Directed airflow carries component heat toward the equipment exhaust and helps maintain a controlled internal temperature. This helps maintain dependable equipment operation.

Frequently Asked Questions

Is 109P0424R3023 easy to install and maintain?

Confirm connector and mounting details, keep the airflow path clear, and isolate power before cleaning or service.

Does 109P0424R3023 have a pressure rating?

The worksheet lists 263.3 Pa. Use the official curve to match it to system resistance.

Is 109P0424R3023 suitable for high-reliability cooling?

Evaluate the exact bearing, life, temperature, alarm, and protection data. Correct sizing and clean airflow are also required for reliable operation.

Which application details matter most for 109P0424R3023?

Review ambient temperature, airflow restriction, contamination exposure, noise limit, mounting orientation, and maintenance access.

Does 109P0424R3023 support PWM speed control?

PWM or sensor functions depend on the exact suffix. Confirm the control lead and interface in the applicable Sanyo Denki datasheet.
